Recover Copper Titanium Anode

Product Name:Recover copper titanium Anode
Standard: ASME, ASTM, EN, UNS, GB, DIN, JIS
Certification: ISO, CE, ROHS
Payment Terms: T/T, L/C, Paypal, Western Union

Product Details

Product Details

Material: TA1 TA2.
Specification: 1.5*1000*700mm or design and production according to the user's actual needs.
Features: corrosion resistance, long life, high electrolysis efficiency, no secondary pollution, low overpotential, good energy saving effect.


Product Description

Advantages of Recover copper titanium Anode:

1. High current density and high electrolysis efficiency;
2. Low trough and good energy saving effect;
3. Corrosion resistance and long life;
4. No pollution, high purity of finished products;
5. Light weight and easy operation;
6. The base material can be reused;


Etching is an important process in the production of printed circuit board. With etching, the copper ion concentration in the etching solution increases continuously, and when it reaches 150g/L, the etching solution will lose its activity.

Due to waste etching solution containing a large number of copper, can be recycled, there are generally two kinds of process, first, on the additive in extraction, the second, recycle directly, is now on the first extraction recovery description:

Waste etching solution - extraction of copper - H2SO4 reverse extraction - electrolysis recovery copper.

Copper sulfate electrolytic process conditions: Cu2+ concentration of 150g/L, 10% H2SO4, 40, anode current density 200-500a /m2.

The titanium anode is plate-shaped, with a size of 1.5*700*1000mm. Currently, it has been used in many PCB factories, with a service life of more than 2 years and up to 5 years.

Product Application

Recover copper titanium Anode Application:

Etching liquid electrolysis recovery copper anode or etching solution to recover copper titanium anode.

1. Standard Exporting package.
2. Original package or neutral package.
3. According to clients ' needs.
4. Shipped in10-35 days after payment.


Our Service

You will have your reply as quickly as possible within 24 working hours
We provide free sample
Guarantee Quality and Quantity
We arrange delivery as soon as possible
There are preferential policies for long-term customers
Customized service is available

Excellent customer service policies on repair/exchange/refund
