Grade 2 Titanium Ring Joint Flanges

Product: Grade 2 Titanium Ring Joint Flanges
Nominal Diameter: 1/2" - 24"
Nominal Pressure: Class150, Class300, Class400, Class600, Class900, Class1500, Class2500
Grade: Grade 2 Pure Titanium
Standard: ASTM/ANSI B16.5
Types: Titanium Ring Joint Flanges
Supply States: (M) Annealed
Technology: Casting、Forging、Cutting、Rolling and CNC Machining
MOQ: 1 pcs
Payment Method: T/T, L/C, Paypal, Western Union

Product Details

Product Details

Grade 2 Titanium Ring Joint Flanges Chemical Composition

Grade

N

C

H

Fe

O

Al

V

Pa

Mo

Ni

Ti

GR 2

0.03

0.08

0.015

0.30

0.25

/

/

/

/

/

bal

Grade 2 Titanium Ring Joint Flanges Physical Properties

Grade

State

Tensile Strength(min)

Yield Strength(min)

Elongation (%)

Ksi

MPa

Ksi

MPa

GR 2

(M)Annealed

50

345

40

275

20


Product Description

Ring Type Joint Flange is a method of ensuring leak proof flange connection at high pressures. A metal ring is compressed into a hexagonal groove on the face of the flange to make the seal.

These Flanges is available in various size, grades, Specification & thickness as per the client requirements. Ring Type Joint Flange in both large and small quantities worldwide and offer you the best prices in the market. These Ring Joint Flanges are used in automobiles, and engineering related industries.



Packing:

1. Packed with wooden case
2. Cardboard case
3. According to the requirements of customers

Shipment type:

1. Sea Freight
2. Air Cargo
3. Express delivery
4. Land Transportation


Our Service

Premium Quality
Fast Delivery
Small Order Acceptable
Wonderful Teamwork
Spot delivery, including delivering small batches of goods
Provide wide-range and complete materials series products
Our application technology expert provide the best material and recommendation
One-stop service
